- CFT-210
- 9N
- 60±2 rpm/min
- 104±3mm
- 70mm×215mm
AATCC crockmeter is used for the rubbing color fastness test of all kinds of textiles, including dyed or printed yarns, fabrics and textile products made from various fibers, as well as textile carpets and other pile fabrics.
Product Description
Application
This instrument is used for the rubbing color fastness test of all kinds of textiles, including dyed or printed yarns, fabrics and textile products made from various fibers, as well as textile carpets and other pile fabrics.
Working Principle
Rub the textile specimen separately with a dry rubbing cloth and a wet rubbing cloth, then evaluate the staining degree on the rubbing cloth.
Standards
The tester is manufactured in accordance with GB/T 3920, ISO 105-X12, AATCC 8, JIS L0849 Type I and other relevant international & domestic standards.
Technical Data
|
Item |
Parameter |
|
Load of rubbing head |
9N |
|
Testing speed |
60±2 rpm/min |
|
Testing stroke |
104±3mm |
|
Diameter of rubbing head |
16mm |
|
Specimen size |
70mm×215mm |
|
Standard rubbing white cotton cloth size |
50mm×50mm |
|
Counter |
LED digital display, programmable from 0 to 9999 cycles |
|
Overall dimension (W×D×H) |
14×59×22 cm |
|
Net weight |
Approx. 15 kg |
|
Power supply |
Single-phase AC 220V, 2.7A |
