Gravure printing ink proofer can print gravure proofs quickly under the experiment conditions,and the method is closed to the actual printing.The gravure ink proofer is used to laboratory production,ink print-ability test and ink product research.It adopts flat intaglio printing work directly for quick proofing in a variety of flexible substrates(such as plastic film,paper,etc.).It is so easy to o
Product Description
Printing Proofer Introduction
This equipment is ideal for providing quick,highly accurate and repeatable samples of gravure inks under lab condition. It may be used for proofing sample、checking printability and R&D for ink products. The machine adopts engraved printing plates direct printing method. Any flexible substrate including films、paper, etc can be printed or laminated, featuring easy operation. It comes complete with: 1 Special Printing Plate for Gravure. We also have ST-RYDJ Printing Proofer (for flexographic ink), it adopts engraved printing plates direct printing method, it can be chosen by customers.
ST-AYDJ Printing Proofer (for Gravure Ink)
ST-AYDJ Printing Proofer (for Gravure Ink) is ideal for providing quick、highly accurate and repeatable samples
of gravure inks under lab condition. It may be used for proofing sample、checking printability and R&D for
ink products. The machine adopts engraved printing plates direct printing
method. Any flexible substrate including films、paper,
etc can be printed or laminated, featuring easy operation. It comes complete
with: 1 Special Printing Plate for Gravure.
We also have ST-RYDJ Printing Proofer (for flexographic ink), it adopts
engraved printing plates direct printing method, it can be chosen by customers.
ST-RYDJ Printing Proofer (for flexo)
Used for providing quick、highly
accurate and repeatable samples of flexographic ink and water based inks. Adopt
solvent resistant impression roller to simulate actual printing method. Any
flexible substrate including films、paper,
etc can be printed or laminated. Different version engraved printing plate can
be selected.
Printing Proofer Technical Specification
|
Model |
ST-AYDJ Gravure Ink Printing Proofer |
|
Electrical Power Source |
220V, 50Hz |
|
Printing Speed |
20, 30, 40, 45 m/min |
|
Printing Range |
95×149 mm |
|
Printing Plate |
150 lines/inch, optional versions: A, B, C, D |
|
Recommended Specimen Size |
120×240 mm |
|
Overall Dimension (L×W×H) |
500×400×350 mm |
|
Packing Dimension (L×W×H) |
580×540×465 mm |
|
Net Weight |
26 kg |
|
Gross Weight |
26.6 kg |
ST-RYDJ Printing Proofer (for flexo):
|
Model |
ST-RYDJ Printing Proofer (for flexo) |
|
Motor Power |
120W |
|
Impression Roller Spec. & Hardness |
Φ50×130mm, Shore A 50 |
|
Metallic Roller Spec. |
Φ60×130mm |
|
Printing Speed |
20, 30, 40, 45 m/min |
|
Printing Length |
150 mm |
|
Power Supply |
220V, 50Hz |
|
Overall Dimension (L×W×H) |
500×425×350 mm |
|
Packing Dimension (L×W×H) |
580×540×465 mm |
|
Net Weight |
26 kg |
|
Gross Weight |
27.8 kg |
Print Proofer Packing List
|
Type |
ST-AYDJ |
ST-RYDJ |
|
Machine |
1 |
1 |
|
Proofing plate |
1 |
1 |
|
Scraper |
2 |
2 |
|
Power cord |
1 |
1 |
|
Instructions |
1 |
1 |
|
Certificate |
1 |
1 |
