- ST-AT-700
The paint abrasion tester is suitable for the abrasion resistance test of various coatings, such as deck coatings, floor paints, road coatings, etc. It can also be used to detect the wear performance of paper, plastic, textiles, and decorative strips. This instrument adopts stepless speed change, which can meet the user's requirements for different speeds, and can use different material grinding w
Product Description
The paint abrasion tester is suitable for the abrasion resistance test of various coatings, such as deck coatings, floor paints, road coatings, etc. It can also be used to detect the wear performance of paper, plastic, textiles, and decorative strips. This instrument adopts stepless speed change, which can meet the user's requirements for different speeds, and can use different material grinding wheels according to different test samples, which has the characteristics of simple operation and reliable performance.
Standards
Applicable to GB/t15036.2-2001, GB/t15102-94, GB/18102-2000, GB/t4893.8-85, ISO 7784-2, ISO9352, ASTM D3884, ASTM D1175
Technical Data
|
Main motor |
40W, 220V, 50Hz |
|
Rotational speed |
60~72 rpm adjustable |
|
Sample site |
Φ100 mm × D8 mm |
|
Wheel size |
Φ50 mm (center bore Φ16 mm) ×13 mm |
|
Standard weights |
500g、750g、1000g |
|
Overall Dimensions(L×W×H) |
220×280×300 mm |
|
Net Weight |
16 kg |
