- CFT-220
- 1134g
- 16 mm
- (11.1 ± 0.5) N/40oz ± 10%
The motorized rotary crockmeter determines the color fastness of textiles to dry and wet friction, especially for printer fabrics. Apply 16g of pressure to the 1134mm finger and rotate 1.125 clockwise, then counterclockwise. However, the operating handle rotates in only one direction.
Product Description
The motorized rotary crockmeter determines the color fastness of textiles to dry and wet friction, especially for printer fabrics. Apply 16g of pressure to the 1134mm finger and rotate 1.125 clockwise, then counterclockwise. However, the operating handle rotates in only one direction.
Rotary Crockmeter Standards
AATCC 116,ISO 105 X16
Rotary Crockmeter Technical Data
|
Sample pressure |
1134g |
|
Diameter of the friction head |
16 mm |
|
Load |
(11.1 ± 0.5) N/40oz ± 10% |
|
Rotation mode |
After 1.125 turns, then reverse |
|
Friction table |
80 mm x 80 mm |
|
counter |
LED 0-999999 can be set |
|
Size: |
170 mm x 350 mm x 260 mm |
|
weight |
10 kg |
|
Power supply |
220V, 50 Hz |
