- STCT-1000
The salt spray corrosion test chamber adapts to the surface treatment of various materials, including paint, electroplating, organic and inorganic coatings, anodizing, rust prevention oil, etc., and undergoes these anti-corrosion treatments to test the corrosion resistance of its products. It can be used to test the corrosion resistance of coating, electroplating, inorganic and organic skin film o
Product Description
The salt spray corrosion test chamber adapts to the surface treatment of various materials, including paint, electroplating, organic and inorganic coatings, anodizing, rust prevention oil, etc., and undergoes these anti-corrosion treatments to test the corrosion resistance of its products. It can be used to test the corrosion resistance of coating, electroplating, inorganic and organic skin film of anti-corrosion treatment, testing the corrosion resistance of the products.
Features
1. It adopts water and electricity separation structure, can effectively prevent water entering into the electrical control chamber and damage accessories.
2. Stable performance
3. User friendly interface and easy for operation
4. Uniform spray
Standards
CNS: 3627, 3385, 4159, 7669, 8886；
JIS: D0201, H8502, H8610, K5400, Z2371；
ISO: 3768, 3769, 3770;
American Society for Testing and Materials: B117, B268
Technical Data
|
Model |
STCT-1000 |
|
Inner box size (length * width * height) |
60*45*40cm (Customizable) |
|
Carton Dimensions (L * W * H) |
107*60*118cm (Customizable) |
|
Equipment materials |
The inner and outer shells are made of imported P.V.C hard plastic plates. and the lid of the tank is made of imported transparent P.V.C. rigid plastic plate |
|
Temperature range |
Room temperature + 5 °C ~ 55 °C |
|
Temperature fluctuations |
≤ ± 0.5 °C |
|
Temperature uniformity |
≤ ± 2 °C |
|
Temperature accuracy |
± 1 °C |
|
Test chamber temperature |
Salt
spray method (NSS ACSS) 35 ± 1 °C |
|
Saturated gas cylinder temperature |
Salt
spray method (NSS ACSS) 47 ± 1 °C |
|
Brine temperature |
35 °C ± 1 °C |
|
Spray volume |
1.0 ~ 2.0 ml/80 cm²/hour |
|
ph |
Salt
spray method (NSS ACSS6.5 ~ 7.2) |
|
Laboratory volume |
108L (customizable) |
|
Brine tank capacity |
15L |
|
impetus |
1#, AC220V volts, 10A |
|
Multiple safety protection devices |
Current discharge protection, overvoltage protection, Overheat protection, overload fuse protection |
|
annex |
1 unit for each test salt/measuring tank/equipment |
