- ST-HT72
- RT +5℃ to 200 / 300℃
- 200℃ or custom made 300℃
- 72L,137L,234L,1000L or custom made
The precision high-temperature test chamber is mainly used to test the performance indicators of components and materials of related products in industries such as electronics and electrical engineering, automotive and motorcycle, aerospace, rubber, plastic, metal, and marine weapons under high temperature and constant temperature changes.
Product Description
The precision high-temperature test chamber is mainly used to test the performance indicators of components and materials of related products in industries such as electronics and electrical engineering, automotive and motorcycle, aerospace, rubber, plastic, metal, and marine weapons under high temperature and constant temperature changes.
Product Features
1. Powder-coated or stainless steel exterior available. Stainless steel surfaces feature a matte, brushed finish. Electrostatic powder coating colors are customizable.
2. Optional double-glazed observation window (optional for temperatures ≤200°C; not recommended for long-term use at 250°C and above).
3. Double-layered, airtight door effectively prevents internal temperature leakage.
4. Touchscreen controller simultaneously displays measured values, setpoints, and time.
5. Temperature uniformity ≤1°C
Technical Data
|
Item |
KH-TK-72C |
KH-TK-137C |
KH-TK-234C |
KH-TK-1000C |
|
Internal Chamber Dimension (W×H×D) |
400×450×400mm |
500×550×500mm |
600×650×600mm |
1000×1000×1000mm |
|
External Overall Dimension (W×H×D) |
750×1100×650mm |
850×1200×750mm |
950×1300×850mm |
1550×1650×1250mm |
|
Temperature Range |
RT+5℃ ~ 200℃; 300℃ or higher temperature can be custom made |
|||
|
Temperature Uniformity |
≤1℃ (Below 200℃) |
|||
|
Temperature Fluctuation |
±0.5℃ |
|||
|
Temperature Deviation |
±1.0℃ |
|||
|
Sensor |
K type / PT100 |
|||
|
Touch Screen Controller |
Chinese & English operation interface; set value operation, program operation; real-time curve tracking, PID auto-calculation; authority protection function |
|||
|
Auxiliary Function |
Fault alarm & fault cause prompt function |
|||
|
Inner Chamber Material |
SUS304 stainless steel |
|||
|
Outer Cabinet Material |
Cold rolled steel plate with electrostatic spraying, or stainless steel plate (spray color optional) |
|||
|
Thermal Insulation Material |
Aluminum silicate thermal insulation cotton |
|||
|
Heating System |
Fin-type stainless steel heater / stainless steel armored heating tube |
|||
|
Standard Accessories |
2 sets of adjustable layered shelves; 1 set of φ50mm test hole; 1 set of glass observation window (optional) |
|||
|
Safety Protection Devices |
Over-temperature protection, fan overcurrent protection, phase sequence protection, etc. |
|||
|
Approx. Weight (Kg) |
100 |
150 |
200 |
400 |
|
Max Power Consumption |
2KW |
3KW |
4KW |
6KW |
|
Power Supply |
AC220V, 50HZ Single-phase three-wire system |
AC380V ±10% ,50HZ Three-phase five-wire system |
||
