- HPT-910
Hydrostatic Pressure Testing Machine is nice in appearance, simple in structure and of high precision and stability as well as easy to operate, it is the it is the necessary testing machine for quality inspection department of kinds of research institutes and pipes manufacturers. Standards: ISO1167, ISO9080, EN921, ASTMD1598, ASTMD1599 ISO13479 etc.
Product Description
Hydrostatic Pressure Testing Machine is nice in appearance, simple in structure and of high precision and stability as well as easy to operate, it is the it is the necessary testing machine for quality inspection department of kinds of research institutes and pipes manufacturers.
Standards: ISO1167, ISO9080, EN921, ASTMD1598, ASTMD1599 ISO13479 etc.
Technical Data
|
Pressure Range Of The Main Engine |
0~10MPa (adjust at random) |
|
Control Range of Water Box |
RT~95℃ |
|
Pressure Resolution of Main Engine |
0.001MPa |
|
Temperature Control Accuracy of Water Box |
±0.5℃ |
|
Constant Pressure Range of Main Engine |
<+2%,-1% of the set value |
|
Temperature Uniformity of The Water Box |
±0.5℃. |
|
Constant Pressure Accuracy of Main Engine |
no lower than ±1% |
|
Temperature Resolution of Water Box |
0.1℃. |
|
Timing Range |
0~9999.59 hours |
|
Timing Accuracy |
≤0.1% |
|
Insulating Layer Thickness of The Water Box |
thicker than 83mm,thinner than 95 mm |
|
Test Stations |
50 roads at most for single machine |
|
Power Supply of Pressure Control System |
AC220V,1.5kw |
|
Power Supply of Temperature Control System |
AC380V,18kw |
|
Water box is equipped with short-circuit protection device, the material is stainless steel |
|
