Surface Tension Meter
  • ST-110
  • 0‑200 mN/m
  • 0.1%
  • 0.1 mN/m
  • 20w

Surface tension machine force forms the surface tension of the liquid, and the amount of tension reflects the physical and chemical properties of the liquid sample, which is one of the important indicators of product quality. Automatic tension tester is designed to test various liquid surface tensions and boundary surface tensions. The sample and accuracy of this method are widely used.

Product Description

Surface tension machine force forms the surface tension of the liquid, and the amount of tension reflects the physical and chemical properties of the liquid sample, which is one of the important indicators of product quality. Automatic tension tester is designed to test various liquid surface tensions and boundary surface tensions. The sample and accuracy of this method are widely used.


Product Features

1. Adopts an electromagnetic force balance sensor, which improves the measurement accuracy and you can adjust the instrument by drawing a point, which is very convenient.
2. The instrument can display the current weight value and test equivalent
3. The instrument can automatically modify the test results with a high-quality screen to extend the screen life
4. The instrument can store 255 records
5. The instrument has a micro printer, you can print the test results at any time.
6. The instrument has an RS232 interface device that can be connected to a computer for easy data processing.


Technical Data

Item Parameter
Measuring range 0‑200 mN/m
Accuracy 0.1% (test result) ± 0.1 mN/m
Sensitivity 0.1 mN/m
Power Supply AC220V ± 20%, 50Hz ± 10%
Power Consumption 20W
Environment Temperature 10 ~ 30℃ (25℃ is the best)
Moisture ≤ 85% RH
Overall Size 200 × 300 × 330 (mm)
Weight 6 kgs
